coreldraw中表格的解决方法

看到太多的在论坛里被CD里面的表格问题所困扰的话题,终究是要解决的。

以下方法是在长期的实际操作中寻找出来的最简捷,最容易理解,最具版本兼容性的方案,请仔细看:

1、我们最常见的应该是从MS EXCEL中获得的表格,现在我们要把它弄到CD中去,直接拷贝所需要的区域;

600) {this.resized=true;this.width=600; this.alt='Click here to open new window';}" onmouseover="if(this.width>600) {this.resized=true; this.width=600; this.style.cursor='hand';}" onclick="if(!this.resized) {return true;} else {window.open('//img.sj33.cn/uploads/allimg/200608/20060824231753641.gif');}" border=0 src="//img.sj33.cn/uploads/allimg/200608/20060824231753641.gif">

2、在CD中建议开一个新文件,然后“选择性粘贴”刚才的内容:

600) {this.resized=true;this.width=600; this.alt='Click here to open new window';}" onmouseover="if(this.width>600) {this.resized=true; this.width=600; this.style.cursor='hand';}" onclick="if(!this.resized) {return true;} else {window.open('//img.sj33.cn/uploads/allimg/200608/20060824231754489.gif');}" border=0 src="//img.sj33.cn/uploads/allimg/200608/20060824231754489.gif">

3、建议去除所有的文字属性,便于下一步的操作;

600) {this.resized=true;this.width=600; this.alt='Click here to open new window';}" onmouseover="if(this.width>600) {this.resized=true; this.width=600; this.style.cursor='hand';}" onclick="if(!this.resized) {return true;} else {window.open('//img.sj33.cn/uploads/allimg/200608/20060824231755379.gif');}" border=0 src="//img.sj33.cn/uploads/allimg/200608/20060824231755379.gif">

4、这里关键了!一定要选择最下面的这项,你将来才有东西可改;

600) {this.resized=true;this.width=600; this.alt='Click here to open new window';}" onmouseover="if(this.width>600) {this.resized=true; this.width=600; this.style.cursor='hand';}" onclick="if(!this.resized) {return true;} else {window.open('//img.sj33.cn/uploads/allimg/200608/20060824231756220.gif');}" border=0 src="//img.sj33.cn/uploads/allimg/200608/20060824231756220.gif">

5、OK!你在页面内应该可以看到表格的雏形了,我这里是个示意表格,你的表格如果在EXCEL更复杂,也会一样转过来。

为了方便编辑,我们要进行如下的分解过程: 解散所有物件;

600) {this.resized=true;this.width=600; this.alt='Click here to open new window';}" onmouseover="if(this.width>600) {this.resized=true; this.width=600; this.style.cursor='hand';}" onclick="if(!this.resized) {return true;} else {window.open('//img.sj33.cn/uploads/allimg/200608/20060824231756487.gif');}" border=0 src="//img.sj33.cn/uploads/allimg/200608/20060824231756487.gif">

6、接下来,我们要把所有表框和文字部分分开到不同的图层:

问题是怎么选中所有的表框? 呵呵,我们用“查找替换”来完成,在“编辑”菜单里面;

新建一个查找选项,勾选“矩形”,这样就能剔出所有表框了

600) {this.resized=true;this.width=600; this.alt='Click here to open new window';}" onmouseover="if(this.width>600) {this.resized=true; this.width=600; this.style.cursor='hand';}" onclick="if(!this.resized) {return true;} else {window.open('//img.sj33.cn/uploads/allimg/200608/20060824231757347.gif');}" border=0 src="//img.sj33.cn/uploads/allimg/200608/20060824231757347.gif">

7、用选择全部,来选中画面上所有的矩形。

600) {this.resized=true;this.width=600; this.alt='Click here to open new window';}" onmouseover="if(this.width>600) {this.resized=true; this.width=600; this.style.cursor='hand';}" onclick="if(!this.resized) {return true;} else {window.open('//img.sj33.cn/uploads/allimg/200608/20060824231758324.gif');}" border=0 src="//img.sj33.cn/uploads/allimg/200608/20060824231758324.gif">

8、打开“对象管理”泊坞窗口,创建一个新的 图层2

600) {this.resized=true;this.width=600; this.alt='Click here to open new window';}" onmouseover="if(this.width>600) {this.resized=true; this.width=600; this.style.cursor='hand';}" onclick="if(!this.resized) {return true;} else {window.open('//img.sj33.cn/uploads/allimg/200608/20060824231800995.gif');}" border=0 src="//img.sj33.cn/uploads/allimg/200608/20060824231800995.gif">

9、嗯,你可以在管理窗口中看到你选中的矩形都是高亮显示的,现在在“对象管理”泊坞窗口中用鼠标拖动它们到新的图层中去,释放之前会有一个图标提示:

600) {this.resized=true;this.width=600; this.alt='Click here to open new window';}" onmouseover="if(this.width>600) {this.resized=true; this.width=600; this.style.cursor='hand';}" onclick="if(!this.resized) {return true;} else {window.open('//img.sj33.cn/uploads/allimg/200608/20060824231800104.gif');}" border=0 src="//img.sj33.cn/uploads/allimg/200608/20060824231800104.gif">

10、好了,现在表框和文字部分完全分离在不同的图层上,编辑起来就容易了。

600) {this.resized=true;this.width=600; this.alt='Click here to open new window';}" onmouseover="if(this.width>600) {this.resized=true; this.width=600; this.style.cursor='hand';}" onclick="if(!this.resized) {return true;} else {window.open('//img.sj33.cn/uploads/allimg/200608/20060824231801245.gif');}" border=0 src="//img.sj33.cn/uploads/allimg/200608/20060824231801245.gif">

11、我们先来编辑文字部分,为避免框线的干扰,在“对象管理”泊坞窗中将表格框线所在的图层点为“不可编辑”

600) {this.resized=true;this.width=600; this.alt='Click here to open new window';}" onmouseover="if(this.width>600) {this.resized=true; this.width=600; this.style.cursor='hand';}" onclick="if(!this.resized) {return true;} else {window.open('//img.sj33.cn/uploads/allimg/200608/20060824231803456.gif');}" border=0 src="//img.sj33.cn/uploads/allimg/200608/20060824231803456.gif">

12、现在你可以任意选择整行整列或者任意的文字框,一起改变它们的字体、大小、颜色、对齐方式……

600) {this.resized=true;this.width=600; this.alt='Click here to open new window';}" onmouseover="if(this.width>600) {this.resized=true; this.width=600; this.style.cursor='hand';}" onclick="if(!this.resized) {return true;} else {window.open('//img.sj33.cn/uploads/allimg/200608/20060824231804844.gif');}" border=0 src="//img.sj33.cn/uploads/allimg/200608/20060824231804844.gif">

13、然后关闭文字层的编辑属性,来修改不太好看的框线:

600) {this.resized=true;this.width=600; this.alt='Click here to open new window';}" onmouseover="if(this.width>600) {this.resized=true; this.width=600; this.style.cursor='hand';}" onclick="if(!this.resized) {return true;} else {window.open('//img.sj33.cn/uploads/allimg/200608/20060824231805928.gif');}" border=0 src="//img.sj33.cn/uploads/allimg/200608/20060824231805928.gif">

14、同样简单的可以整行整列的修改框线的粗细以及表格的填充颜色,很EZ吧!

注意哦,整个表格的外框,在表格框的最底层,你可以找到它,设置不同的边宽或颜色

做到这一步,相信你就可以举一反三,编辑出你自己的漂亮表格来了!

重复一次,这个方法没有版本限制,在CD9~CDX3都是一样运用的。开心了吗?

600) {this.resized=true;this.width=600; this.alt='Click here to open new window';}" onmouseover="if(this.width>600) {this.resized=true; this.width=600; this.style.cursor='hand';}" onclick="if(!this.resized) {return true;} else {window.open('//img.sj33.cn/uploads/allimg/200608/20060824231806264.gif');}" border=0 src="//img.sj33.cn/uploads/allimg/200608/20060824231806264.gif">
