关于solidworks中的剖面线

solidworks的剖面线线型定义和autocad相同,它使用了autocad的剖面线定义方法,与autocad通用.因此,可以对剖面线进行定义.

方法:修改\SolidWorks\lang\chinese-simplified\sldwks.prn

用笔记本打开该文件,添加需要的线形.如

;; Based on AutoCAD Ver.13.0s Hatch Pattern File

;;;; solidworks 区域剖面线定义文件 ::

*金属, (Iron BrickStone), ANSI Iron, Brick, Stone masonry

45, 0,0, 0,.125

*塑料, (Lead Zinc Mg), ANSI Lead, Zinc, Magnesium, Sound/Heat/Elec Insulation

45, 0,0, 0,.125

135, 0,0, 0,.125

*玻璃,AR-GLASS@1.0

45,0,0,0,0.5, 0.5,-0.5

45,0,0.1414214, 0,0.5, 0.3,-0.7

45,0.1414214,0, 0,0.5, 0.3,-0.7

*软木, Cork material@1.0

0, 0,0, 0,.125

135, .0625,-.0625, 0,.35355339, .176776696,-.176776696

135, .09375,-.0625, 0,.35355339, .176776696,-.176776696

135, .125,-.0625, 0,.35355339, .176776696,-.176776696

*无, None

删除不需要的定义类型,可以大大提高solidworks 的启动速度.
