如何对UG文件进行公制英制转换?

1. 只进行单位转换,保证实际长度一致.(When you just want to convert the Unit but keep the same length.)

a. Start->Program->nx 3.0->nx tools->Command Prompt

b. Cd path:nx3.0ugii

c. Ug_convert_part -in (-mm) path:partname.prt

2. 进行单位转换,保证数值一致,实际长度放大或缩小.(When you make a mistake unit, So you want to convert the Unit but hope keep the same parameter value. )

a. 启动 UG, 打开UG part 文件,进入Modeling.

b. Toolbox->Expression->export 产生 partname.exp 文件.

c. Start->Program->nx 3.0->nx tools->Command Prompt

d. Cd path:nx3.0ugii

e. Ug_convert_part -in (-mm) path:partname.prt

f. Close UG part 文件, 重新打开 UG part 文件。进入Modeling.

g. Toolbox->Expression->Import with option(Replace Existing)
